3-5. Disassembly, Reassembly and Lubrication

[Disassembly Flow]
7010, 7010-300, 7010R (Printer Part)
Unit, Head
Unit, Roller Platen
SA, Ope-pane PCB and SA, Cover Open Sens
SA1, Top Cover
Top Cover
Connectors on the SA,
Main PCB
See 3-5-1.
See 3-5-2.
See 3-5-7.
Unit, Power Supply
SA, Main PCB and Unit, Centro PCB
Unit, Mechanism
Unit, Frame Ribbon L
SA, Front Tension Arm
SA, Frame Ribbon R
Unit, Frame Rear
Unit, Frame U
SA, Sensor U (Fixed)
SA, Sensor Bottom (Fixed)
Unit, Motor
SA, Connect PCB (7010/7010-300)
Unit, Sensor Adjust
See 3-5-10.
SA, Base Guide Open
3-5. Disassembly, Reassembly and Lubrication
See 3-5-4.
See 3-5-5 (1).
See 3-5-8.
See 3-5-12.
See 3-5-13.
See 3-5-14.
See 3-5-15.
See 3-5-16.
See 3-5-17 "Unit, Frame".
See 3-5-17 "Unit, Frame".
See 3-5-17 "Unit, Frame".
See 3-5-11.
3-7
See 3-5-3.
See 3-5-6.
SA, Fan
See 3-5-5 (2).
See 3-5-17 "Unit, Frame".
SA, Sensor U (Adjustable)
SA, Sensor Bottom
(Adjustable)
