PARTS LIST for 7010R
Location Part Name
1-21 SA, Power SW Cable
1-22 Rail, Guide U
1-23 Rail, Guide Base
1-24 Guide, Top Cover
1-25 -
1-26 SA, Ope-pane
1-27 -
1-28 SA, Front Right
1-29 SA, Case L
1-30 -
1-31 Plate, Cable Cover
1-32 Cover, Sensor Adjust
1-33 Holder, Paper Shaft Right
1-34 Cover, Inner PCB Front
1-35 SA, Cover Inner PCB Rear
1-36 Screw, FH, M3.0x6
1-37 Screw, BH, M3.0x5
1-38 Screw, PH (SW+PW), M3.0x5
1-39 Screw, BH, M3.0x5K
1-40 Screw, PH (SW+PW), M4.0x30
TITLE: General Assembly
Drawing No. 1
Q'ty/
Part No.
Unit
1 Including Inlet
1
1
1
-
1 Ref.: Drawing No. 11 / 7010, 7010-300
-
1 Ref.: Drawing No. 13 / 7010, 7010-300
1
-
1
1
1
1
1
2
19
15
11
4
5-61
Sheet No. 2/3
Rev. No. 0
Dedicated for
Remarks
7010R
