Tally Dascom 7106 Installation Manual

Ethernet interface
Hide thumbs Also See for 7106:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
7106 7206 7010
Installation Guide
Ethernet Interface
– 1 –

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7106 and is the answer not in the manual?

Questions and answers

Related Manuals for Tally Dascom 7106

Summary of Contents for Tally Dascom 7106

  • Page 1 7106 7206 7010 Installation Guide Ethernet Interface – 1 –...
  • Page 2 © August 2010 DASCOM Europe GmbH...

  • Page 3: Replacing The Interface Board

    Installation Guide This guide explains how to install the Ethernet LAN card in your label printer. You should conult your dealer or distributor for more information if you are not completely sure of how to perform this operation. Always turn off the power to the printer and remove Caution the power cord before replacing the interface board.
  • Page 4 The new board is slightly larger than the original board, so the interface cable will need to be tucked in carefully. 4. Use the two screws that you removed to re-fix the bracket in place. 7106 7206 Back of printer LAN interface board...
  • Page 5 Testing the Interface Board 5. To test the interface board’s correct operation, connect the power cord and the ethernet cable to the printer, insert some standard media, preferably 4” x 4” labels, (100mm x 100mm), then switch on the power. 6.
  • Page 6 Configuring the Interface using Explorer 8. To configure the network board, you can use the “PrintServer Network Tools” included on the CD supplied with the printer. However, the easiest way to configure the board is to use a Web Browser, such as Internet Explorer, running on a PC connected to the same network.
  • Page 7 10. On the self-test, under the TCP/IP section, there will be a line saying “IP address” together with four groups of digits separated by dots. It should also say “asigned by DHCP” next to it. 1 1. Start “Internet Explorer” or a similar web browser on a PC connected to the same network.
  • Page 8 DASCOM REPRESENTATIVES GERMANY UNITED KINGDOM DASCOM Europe GmbH DASCOM GB Ltd Heuweg 3 Hart House, Priestley Road D-89079 Ulm Basingstoke, Hampshire Deutschland RG24 9PU, England Tel.: +49 (0) 731 2075 0 Phone: +44 (0) 1256 481481 Fax: +49 (0) 731 2075 100 Fax: +44 (0) 1256 481400 www.dascom.com www.dascom.com...
