Specifications; Table A-4 Physical And Environmental Specifications - Silicon Graphics Origin 300 User Manual

Specifications
007-4498-002
Table A-4 shows the physical and environmental specifications for the SGI Origin 300
base module.
Table A-4 Physical and Environmental Specifications
Feature Specification
Height 3.46 in. (8.80 cm)
Width 19.0 in. (48.3 cm) (front panel width)
17.07 in. (43.36 cm) (chassis width)
Depth 26 in. (66 cm) (without bezel)
26.8 in. (68.0 cm) (with bezel)
Weight 36.0 lb (16.4 kg)
Temperature, +5 ˚C (+41 ˚F) to +35 ˚C (+95 ˚F) (up to 1500 m / 5000 ft)
operating +5 ˚C (+41 ˚F) to +30 ˚C (+86 ˚F) (1500 m to 3000 m / 5000 ft to 10000 ft)
Temperature, -40 ˚C (-40 ˚F) to +60 ˚C (+140 ˚F)
non-operating
Humidity 10% to 95% RH, noncondensing
Altitude Sea level to 40,000 ft (nonoperating)
Sea level to 10,000 ft (3000 m) (operating)
Noise 50 dB(A) maximum
Heat dissipation 938 Btu/hr maximum
Input power 110/220 Vac autosensing (~275 W)
SGI Origin 300 Base Module
119
