A: Technical Specifications
116
Table A-1 lists the specifications of the short rack.
Short-rack Specifications (with Skins)
Table A-1
Characteristic
Height
Width
Depth
Weight (maximum)
Shipping weight (maximum)
Table A-2 lists the specifications of the tall rack.
Table A-2 Tall-rack Specifications
Characteristic
Height
Width
Depth
Weight (maximum)
Shipping weight (maximum)
Specification
36.06 in. (916.00 mm)
25.38 in. (645.00 mm)
40.63 in. (1032.00 mm)
488 lb (221 kg)
563 lb (255 kg)
Specification
75.82 in. (1925.83 mm)
23.62 in. (599.95 mm)
41.25 in. (1048.00 mm)
1,100 lb (499 kg)
1,281 lb (581 kg)
007-4498-002
