A: Technical Specifications

Internal Components and Features

DIMMs
124
The internal components of the SGI Origin 300 base module are shown in Figure A-6 and
described in the following subsections:
• "IP45 Motherboard" on page 125
• "Dual-inline Memory Modules (DIMMs)" on page 126
• "I/O-8 Board Assembly" on page 127
• "SCSI Backplane Board and Drive Options" on page 128
• "Power Supply" on page 128
• "Fans" on page 128
SCSI backplane board
Fans
IP45 motherboard
Figure A-6 Internal Components
Internal disk drives
L1 display
Fan
I/O-8 assembly
Power supply
