USB Hub

007-4498-002
Table B-3 lists the connectors that are located on the USB hub (refer to Figure B-5).
Table B-3 USB Hub Connectors
Connectors Pin Number Locations
USB type A Refer to Figure B-10 on page 175
USB type B Refer to Figure B-11 on page 176
Note: The USB hub might look different than the one shown in Figure B-5.
USB type B port
(to L2 controller)
Figure B-5 USB Hub Connectors
To power adapter
Pin Assignments
Refer to Table B-6 on page 175
Refer to Table B-7 on page 176
USB type A port
(to Origin 300 base
modules)
USB Hub
