A: Technical Specifications

Internal Components

134
The AC- and DC-powered NUMAlink modules contain the following internal
components, which are described in the subsections that follow (refer to Figure A-12 and
Figure A-13).
• Router printed circuit board (PCB)
• Power board
• L1 controller
The AC-powered NUMAlink module also contains a power supply (refer again to
Figure A-12). The DC-powered NUMAlink module does not have an internal power
supply.
Figure A-12 Internal View of the AC-powered NUMAlink Module
Power board
Power supply
Router
PCB
