1: Introduction
6
Both rack types have the following characteristics:
• 19-in. mounting rails to support the components within the rack.
• Front and rear doors.
• Cable management hardware in the rear of the rack.
• Four castors, two of which are swivel castors.
• Seismic tie-down attachment points.
Note: Tall racks also have leveling pads; short racks do not have leveling pads.
Figure 1-5 shows the front view of the short rack.
Figure 1-5 Front View of the Short Rack
007-4498-002
