Figure 1-13 PCI Expansion Module
Figure 1-14 shows the PCI card slot numbering on the PCI expansion module.
Bus 1 Bus 2
Slot Slot
1 2 1
PCI Card Slot Numbering on the PCI Expansion Module
Figure 1-14
Bus 3
Slot
2 1 2 1
Optional System Components
Bus 4 Bus 5
Slot Slot
2 1 2
Bus 6
Slot
1 2
