Sgi Total Performance 900 (Tp900) Storage Module; Figure B-4 Rear Panel Of Tp900 Storage Module - Silicon Graphics Origin 300 User Manual

B: Connector Pinouts

SGI Total Performance 900 (TP900) Storage Module

168
Figure B-4 shows the two SCSI port connectors that are located on the rear panel of the
TP900 storage module. Figure B-8 on page 172 shows how the pin numbers are
distributed on the SCSI connector, and Table B-4 on page 172 lists the pin assignments.
OUTPUT
GOOD
FAULT
Rear Panel of TP900 Storage Module
Figure B-4
SCSI port connectors
OUTPUT
GOOD
FAULT
