A: Technical Specifications

L2 Controller

Specifications
138
The L2 controller is a rack-level controller; it communicates with all of the L1 controllers
within the rack. For example, it receives status and error messages from the L1
controllers. The L2 controller is housed in a sheet metal box that is 1U high and is located
at the top rear of the rack.
You can access the L2 controller via the system console.
Table A-7 lists the specifications of the L2 controller.
Table A-7 L2 Controller Specifications
Characteristic Specification
Height 1.75 in. (44.45 mm)
Width 14.0 in. (355.6 mm)
Depth 6.0 in. (165.1 mm)
Input power +48 Vdc (~30 W)
