007-4498-002
The 4mm DAT can be mounted in the Origin 300 rack or placed on a table. All other
supported tape devices are housed within one of the following libraries: L20, L40, L80,
L180, or L700 (refer to Table 1-2 and Figure 1-18).
Note: In Table 1-2, device transfer rates are dictated by the profile of the data being
transferred and are likely to be less than the rated speed, depending on the size of files
and the block size.
Table 1-2 Tape Drive Libraries
Library Specifications
L20 Number of cartridge slots: 10 or 20
Number of drives: 1 or 2
Supported drives: DLT 8000 (native mode), ULTRIUM LTO, and SDLT
Cartridge capacity:
DLT 8000: 800 GB (20 slots, UNC) - 1.6 TB (20 slots, COM)
ULTRIUM LTO: 2.0 TB (20 slots, UNC) - 4.0 TB (20 slots, COM)
SDLT: 2.2 TB (20 slots, UNC) - 4.4 TB (20 slots, COM)
Drive data rate:
DLT 8000: 43.2 GB/hr (2 drives, UNC) - 86.4 GB/hr (2 drives, COM)
ULTRIUM LTO: 108 GB/hr (2 drives, UNC) - 216 GB/hr (2 drives, COM)
SDLT: 79.2 GB/hr (2 drives, UNC) - 158.4 GB/hr (2 drives, COM)
L40 Number of cartridge slots: 20 or 40
Number of drives: 1 to 4
Supported drives: DLT 8000 (native mode), ULTRIUM LTO, and SDLT
Cartridge capacity:
DLT 8000: 1.6 TB (40 slots, UNC) - 3.2 TB (40 slots, COM)
ULTRIUM LTO: 4.0 TB (40 slots, UNC) - 8.0 TB (40 slots, COM)
SDLT: 4.4 TB (40 slots, UNC) - 8.8 TB (40 slots, COM)
Drive data rate:
DLT 8000: 86.4 GB/hr (4 drives, UNC) - 172.8 GB/hr (4 drives, COM)
ULTRIUM LTO: 216 GB/hr (4 drives, UNC) - 432 GB/hr (4 drives, COM)
SDLT: 158.4 GB/hr (4 drives, UNC) - 316.8 GB/hr (4 drives, COM)
Key: UNC = uncompressed, COM = compressed
Optional System Components
25
