System Specifications And Regulatory Overview; Operating Environment - Silicon Graphics NAS MIS Setup Manual

B.

Operating Environment

007-5921-001
Appendix B

System Specifications and Regulatory Overview

This appendix provides basic environmental operating requirements and regulatory information
for the MIS NAS server.
Table B-1 describes the technical specifications for the SGI MIS platform.
Table B-1
Technical Specifications
Attribute Specification
Overview
Profile 4U Standard-depth chassis
Product type SGI MIS NAS Server Platform, or SGI MIS JBOD Unit
Connectivity Up to four SGI MIS NAS JBOD units per SGI MIS NAS Server
Mount –Standard 19-inch rack-compatible rail mount (weight-dependent)
–SGI 19-inch Destination Rack (D-Rack), 42U
–Up to 5 chassis maximum per D-Rack
Chassis Dimensions
Height 6.94" (176 mm)
Width 16.9" (429.2 mm)
Depth 36" (914.4 mm)
Max weight 220 lbs.
Power
AC Input 100–240 VAC (50-60Hz), single or three phase
59
