Table 5- 2
Power Module frame size FSA, with and without
line filter
Power Module frame size FSB, with and without
line filter
Power Module frame size FSC, with and without
line filter
AC Drive
Manual, 06/2019, 6SL3097-5AL00-0BP1
Overview of PM240-2 Power Modules (FSA to FSG)
5.2 Blocksize Power Modules (PM240-2)
Push through Power Module frame size FSA,
with and without line filter
Push through Power Module frame size FSB,
with and without line filter
Push through Power Module frame size FSC,
with and without line filter
Power Modules
77
