Phaser 3330 Rear and Side Views
No.
Description
1.
Tray 1 Rear Access Cover
2.
Power Receptacle
3.
Power Switch
4.
5V Output (Not Used)
Xerox Internal Use Only
No.
Description
5.
USB Cable Port
6.
Network Cable Port
7.
Duplex Assembly
8.
Rear Door
Phaser 3330 and WorkCentre 3335/3345
General Information
1-13
Service Manual
