Fuser Errors - Xerox Phaser 3330 Service Manual

Troubleshooting

Fuser Errors

Fuser Door Open
The Rear Door is not securely latched.
Applicable Error
• None
Initial Actions
• Close the Rear Door until it locks.
• Turn the printer off and then on again.
• If the problem persists continue troubleshooting.
Troubleshooting Reference Table
Applicable Parts
• SMPS, (PL1.0.65, Parts List 1.0 Phaser
3330 Main)
Troubleshooting Procedure Table
Step Actions and Questions
1. Re-seat CN18 on the Main PWB and CN4 on
the SMPS.
Does the error persist?
2. Enter dC330 Component
01-200 to check the Rear Door open switch
for correct operation. Repair or replace as
required.
2-66 Phaser 3330 and WorkCentre 3335/3345
Service Manual
Wiring and Plug/Jack Map Reference
• Phaser 3330 Main PWB Connector Designators
• Phaser 3330 Control Panel PWB
• Wiring Diagrams for P3330/WC3335/WC3345
• WorkCentre 3335/3345 Main PWB Connector Designators
• DADF PWB
• SMPS PWB
Yes
Go to step 2.
Control, code -
No
Complete.
-
