Lantronix SGX 5150 Command Reference Manual page 74

ip address <ip ad-
dress/cidr>
last client disconnect
timeout <seconds>
mode always up
mode triggered
multicast forwarding dis-
able
multicast forwarding en-
able
network name <text>
no dns redirect
no network name
no passphrase
passphrase <text>
show
show history
show status
ssid broadcast disable
ssid broadcast enable
state disable
state enable
suite none
suite wpa
trigger ap
suite wpa2
write
action (config-action-select) level commands
clrscrn
eth0 link state change
exit
on scheduled reboot
show history
usb0 link state change
wlan0 link state change
write
advanced (config-profile-advanced:default_infrastructure_profile) level commands
apply wlan
basic
clrscrn
default tx power maxi-
mum
exit
power management dis-
able
SGX™ 5150 IoT Device Gateway Command Reference
Sets the IP address of Access Point. Formats accepted: 192.168.1.1 (default mask)
192.168.1.1/24 (CIDR) "192.168.1.1 255.255.255.0" (explicit mask)
Sets the Last Client Disconnect Timeout for SoftAP trigger mode in seconds.
Sets the AP mode to Always Up.
Sets the AP mode to Triggered.
Disables Multicast Forwarding.
Enables Multicast Forwarding.
Set Network Name (SSID). <text> = Network Name(SSID).
Clears the DNS redirect.
Clears Network Name (SSID).
Clears the password.
Sets the value for the password. <text> = put quotes around the characters (max 63).
Displays the current configuration.
Displays the last 20 commands entered during the current CLI session.
Displays statistics.
Disables SSID Broacast.
Enables SSID Broadcast.
Disables Access Point.
Enables Access Point.
Sets the security suite to None.
Sets the security suite to WPA.
Triggers soft AP.
Sets the security suite to WPA2.
Stores the current configuration in permanent memory.
Clears the screen.
Enters the eth0 link state change alarm level.
Exits to the config level.
Enters the on scheduled reboot alarm level.
Displays the last 20 commands entered during the current CLI session.
Enters the usb0 link state change alarm level.
Enters the wlan0 link state change alarm level.
Stores the current configuration in permanent memory.
Try out WLAN settings without saving them to Flash. If the settings do not work, when you
reboot the device, it will still have the original settings.
Switch to basic level
Clears the screen.
Restores the maximum TX power to the default value (14 dBm).
Exit to the profiles level
Disables power management.
5: Commands and Levels
74
