EEA Register – HT67F2350/HT67F2360
Bit 7
Name EEA7
R/W R/W
POR 0
Bit 7~0 EEA7~EEA0: Data EEPROM address bit 7 ~ bit0
EEAL Register – HT67F2370/HT67F2390
Bit 7
Name EEAL7
R/W R/W
POR 0
Bit 7~0 EEAL7~EEAL0: Data EEPROM low byte address bit 7 ~ bit 0
EEAH Register – HT67F2370
Bit 7
Name —
R/W —
POR —
Bit 7~1 Unimplemented, read as "0"
Bit 0 EEAH0: Data EEPROM high byte address bit 0
EEAH Register – HT67F2390
Bit 7
Name —
R/W —
POR —
Bit 7~2 Unimplemented, read as "0"
Bit 1~0 EEAH1~EEAH0: Data EEPROM high byte address bit 1 ~ bit 0
EED Register
Bit 7
Name D7
R/W R/W
POR 0
D7~D0: Data EEPROM data bit 7 ~ bit 0
Bit 7~0
