Counter Value
CCRA
CCRP
PTnON
Software Cleared by
Trigger CCRA match
PTCKn pin
PTnPAU
PTnPOL
No CCRP
CCRP Int. Flag
Interrupts
generated
PTMnPF
CCRA Int. Flag
PTMnAF
PTMn O/P Pin
(PTnOC=1)
PTMn O/P Pin
(PTnOC=0)
Pulse Width
set by CCRA
Note: 1. Counter stopped by CCRA
2. CCRP is not used
3. The pulse triggered by the PTCKn pin or by setting the PTnON bit high
4. A PTCKn pin active edge will automatically set the PTnON bit high.
5. In the Single Pulse Output Mode, PTnIO [1:0] must be set to "11" and can not be changed.
6. n=0, 1, 4, 5, 6 or 7 for 10-bit PTM while n=2 or 3 for 16-bit PTM
Rev. 1.60
Advanced A/D Flash MCU with LCD & EEPROM
Counter stopped by
CCRA
Pause
Auto. set by
PTCKn pin
Software
Trigger
PTCKn pin
Trigger
Single Pulse Output Mode
164
HT67F2350/HT67F2360
HT67F2370/HT67F2390
PTnM [1:0] = 10 ; PTnIO [1:0] = 11
Counter Reset when
PTnON returns high
Counter Stops
Resume
by software
Software
Software
Clear
Trigger
Output Inverts
when PTnPOL = 1
May 16, 2019
Time
Software
Trigger
