Instruction Definition

ADC A,[m]
Add Data Memory to ACC with Carry
Description
The contents of the specified Data Memory, Accumulator and the carry flag are added.
The result is stored in the Accumulator.
Operation
ACC ← ACC + [m] + C
Affected flag(s)
OV, Z, AC, C, SC
ADCM A,[m]
Add ACC to Data Memory with Carry
Description
The contents of the specified Data Memory, Accumulator and the carry flag are added.
The result is stored in the specified Data Memory.
Operation
[m] ← ACC + [m] + C
Affected flag(s)
OV, Z, AC, C, SC
Add Data Memory to ACC
ADD A,[m]
Description
The contents of the specified Data Memory and the Accumulator are added.
The result is stored in the Accumulator.
Operation
ACC ← ACC + [m]
Affected flag(s)
OV, Z, AC, C, SC
ADD A,x
Add immediate data to ACC
Description
The contents of the Accumulator and the specified immediate data are added.
The result is stored in the Accumulator.
Operation
ACC ← ACC + x
Affected flag(s)
OV, Z, AC, C, SC
ADDM A,[m]
Add ACC to Data Memory
Description
The contents of the specified Data Memory and the Accumulator are added.
The result is stored in the specified Data Memory.
Operation
[m] ← ACC + [m]
Affected flag(s)
OV, Z, AC, C, SC
Logical AND Data Memory to ACC
AND A,[m]
Description
Data in the Accumulator and the specified Data Memory perform a bitwise logical AND
operation. The result is stored in the Accumulator.
Operation
ACC ← ACC "AND" [m]
Affected flag(s)
Z
AND A,x
Logical AND immediate data to ACC
Description
Data in the Accumulator and the specified immediate data perform a bit wise logical AND
operation. The result is stored in the Accumulator.
Operation
ACC ← ACC "AND" x
Affected flag(s)
Z
ANDM A,[m]
Logical AND ACC to Data Memory
Description
Data in the specified Data Memory and the Accumulator perform a bitwise logical AND
operation. The result is stored in the Data Memory.
Operation
[m] ← ACC "AND" [m]
Affected flag(s)
Z
Rev. 1.60
Advanced A/D Flash MCU with LCD & EEPROM
272
HT67F2350/HT67F2360
HT67F2370/HT67F2390
May 16, 2019
