HT67F2350/HT67F2360
HT67F2370/HT67F2390
Advanced A/D Flash MCU with LCD & EEPROM
• PGS0 Register – HT67F2360/HT67F2370/HT67F2390
Bit
7
Name
PGS07
R/W
R/W
POR
0
PGS07~PGS06: PG3 pin function selection
Bit 7~6
00, 01, 10: PG3
11: COM3
Bit 5~4
PGS05~PGS04: PG2 pin function selection
00, 01, 10: PG2
11: COM2
Bit 3~2
PGS03~PGS02: PG1 pin function selection
00, 01: PG1
10: TX2
11: COM1
Bit 1~0
PGS01~PGS00: PG0 pin function selection
00, 01: PG0
10: RX2
11: COM0
• PGS1 Register
Bit
7
Name
PGS17
R/W
R/W
POR
0
Bit 7~6
PGS17~PGS16: PG7 pin function selection
00, 01, 10: PG7
11: COM3
Bit 5~4
PGS15~PGS14: PG6 pin function selection
00, 01, 10: PG6
11: COM2
PGS13~PGS12: PG5 pin function selection
Bit 3~2
00, 01, 10: PG5
11: COM1
Bit 1~0
PGS11~PGS10: PG4 pin function selection
00, 01, 10: PG4
11: COM0
• PHS0 Register – HT67F2360/HT67F2370/HT67F2390
Bit
7
Name
PHS07
R/W
R/W
POR
0
Bit 7~6
PHS07~PHS06: PH3 pin function selection
00, 01: PH3/PTCK5
10: AN13
11: SEG41
Bit 5~4
PHS05~PHS04: PH2 pin function selection
00, 01: PH2/PTCK4
10: AN12
11: SEG42
Rev. 1.60
6
5
4
PGS06
PGS05
PGS04
R/W
R/W
R/W
0
0
0
6
5
4
PGS16
PGS15
PGS14
R/W
R/W
R/W
0
0
0
6
5
4
PHS06
PHS05
PHS04
R/W
R/W
R/W
0
0
0
125
3
2
1
PGS03
PGS02
PGS01
R/W
R/W
R/W
0
0
0
3
2
1
PGS13
PGS12
PGS11
R/W
R/W
R/W
0
0
0
3
2
1
PHS03
PHS02
PHS01
R/W
R/W
R/W
0
0
0
May 16, 2019
0
PGS00
R/W
0
0
PGS10
R/W
0
0
PHS00
R/W
0
