Counter Value
0x3FF
CCRA
CCRP
PTnON
PTnPAU
PTnPOL
CCRA Int.
Flag PTMnAF
CCRP Int.
Flag PTMnPF
PTMnPF not
generated
PTMn O/P
Pin
Output pin set to
with PTMnAF flag
initial Level Low if
PTnOC=0
Here PTnIO [1:0] = 11
Toggle Output select
Note: 1. With PTnCCLR=1, a Comparator A match will clear the counter
2. The PTMn output pin is controlled only by the PTMnAF flag
3. The output pin is reset to its initial state by a PTnON bit rising edge
4. A PTMnPF flag is not generated when PTnCCLR =1
5. The 10-bit PTM maximum counter value is 0x3FF while the 16-bit PTM maximum counter value is
0xFFFF.
6. n=0, 1, 4, 5, 6 or 7 for 10-bit PTM while n=2 or 3 for 16-bit PTM
Rev. 1.60
Advanced A/D Flash MCU with LCD & EEPROM
CCRA > 0 Counter cleared by CCRA value
Resume
Pause
Output not affected by
PTMnAF flag. Remains High
Output Toggle
until reset by PTnON bit
Note PTnIO [1:0] = 10
Active High Output select
Compare Match Output Mode – PTnCCLR=1
160
HT67F2350/HT67F2360
HT67F2370/HT67F2390
PTnCCLR = 1; PTnM [1:0] = 00
CCRA = 0
Counter overflow
CCRA=0
Stop
Counter Restart
No PTMnAF flag
generated on
CCRA overflow
Output does
not change
Output Inverts
when PTnPOL is high
Output Pin
Reset to Initial value
Output controlled by
other pin-shared function
May 16, 2019
Time
