Advanced A/D Flash MCU with LCD & EEPROM
• FARH Register – HT67F2360
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
Bit 5~0 Flash Memory Address bit 13 ~ bit 8
• FARH Register – HT67F2370
Bit 7
Name —
R/W —
POR —
Bit 7 Unimplemented, read as "0"
Bit 6~0 Flash Memory Address bit 14 ~ bit 8
• FARH Register – HT67F2390
Bit 7
Name A15
R/W R/W
POR 0
Bit 7~0 Flash Memory Address bit 15 ~ bit 8
• FD0L Register
Bit 7
Name D7
R/W R/W
POR 0
Bit 7~0 The first Flash Memory data bit 7 ~ bit 0
Note that the data written into the low byte data register FD0L will only be stored in
the FD0L register and not be loaded into the lower 8-bit write buffer.
• FD0H Register
Bit 7
Name D15
R/W R/W
POR 0
Bit 7~0 The first Flash Memory data bit 15 ~ bit 8
Note that when the 8-bit data is written into the high byte data register FD0H, the
whole 16-bit data stored in the FD0H and FD0L registers will simultaneously be
loaded into the 16-bit write buffer and then the content of the Flash Memory address
register pair, FARH and FARL, will be incremented by one.
• FD1L Register
Bit 7
Name D7
R/W R/W
POR 0
Bit 7~0 The second Flash Memory data bit 7 ~ bit 0
