SLEDC0 Register
Bit 7
Name SLEDC07 SLEDC06 SLEDC05 SLEDC04 SLEDC03 SLEDC02 SLEDC01 SLEDC00
R/W R/W
POR 0
Bit 7~6 SLEDC07~SLEDC06: PB7~PB4 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 5~4 SLEDC05~SLEDC04: PB3~PB0 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 3~2 SLEDC03~SLEDC02: PA7~PA4 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 1~0 SLEDC01~SLEDC00: PA3~PA0 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
SLEDC1 Register
Bit 7
Name SLEDC17 SLEDC16 SLEDC15 SLEDC14 SLEDC13 SLEDC12 SLEDC11 SLEDC10
R/W R/W
POR 0
Bit 7~6 SLEDC17~SLEDC16: PD6~PD4 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 5~4 SLEDC15~SLEDC14: PD3~PD0 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 3~2 SLEDC13~SLEDC12: PC7~PC4 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 1~0 SLEDC11~SLEDC10: PC3~PC0 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Rev. 1.60
Advanced A/D Flash MCU with LCD & EEPROM
6 5 4
R/W R/W R/W
0 0 0
6 5 4
R/W R/W R/W
0 0 0
114
HT67F2350/HT67F2360
HT67F2370/HT67F2390
3 2 1
R/W R/W R/W
0 0 0
3 2 1
R/W R/W R/W
0 0 0
May 16, 2019
0
R/W
0
0
R/W
0
