HT67F2350/HT67F2360
HT67F2370/HT67F2390
Advanced A/D Flash MCU with LCD & EEPROM
• PCS0 Register
Bit 7
Name PCS07
R/W R/W
POR 0
PCS07~PCS06: PC3 pin function selection
Bit 7~6
00: PC3/PTCK0/PTP4I
01: PTP4
10: AN3
11: SEG50
PCS05~PCS04: PC2 pin function selection
Bit 5~4
00: PC2/PTP0I
01: PTP0
10: AN2
11: SEG51
PCS03~PCS02: PC1 pin function selection
Bit 3~2
00: PC1
01: C0X
10: VREF
11: AN1
PCS01~PCS00: PC0 pin function selection
Bit 1~0
00: PC0
01: VREFI
10: AN0
11: SEG52
• PCS1 Register
Bit 7
Name PCS17
R/W R/W
POR 0
PCS17~PCS16: PC7 pin function selection
Bit 7~6
00: PC7/INT3/STCK0/PTP6I
01: PTP6
10: AN7
11: SEG46
PCS15~PCS14: PC6 pin function selection
Bit 5~4
00: PC6/STP0I
01: STP0
10: AN6
11: SEG47
PCS13~PCS12: PC5 pin function selection
Bit 3~2
00: PC5/PTCK1/PTP5I
01: PTP5
10: AN5
11: SEG48
PCS11~PCS10: PC4 pin function selection
Bit 1~0
00: PC4/PTP1I
01: PTP1
10: AN4
11: SEG49
