Bit 2 FWT: Flash memory Write Initiate control
0: Do not initiate Flash memory write or Flash memory write process is completed
1: Initiate Flash memory write process
This bit is set by software and cleared by hardware when the Flash memory write
process is completed.
FRDEN: Flash memory Read Enable control
Bit 1
0: Flash memory read disable
1: Flash memory read enable
Bit 0 FRD: Flash memory Read Initiate control
0: Do not initiate Flash memory read or Flash memory read process is completed
1: Initiate Flash memory read process
This bit is set by software and cleared by hardware when the Flash memory read
process is completed.
• FC1 Register
Bit 7
Name D7
R/W R/W
POR 0
Bit 7~0 D7~D0: Whole chip reset pattern
When user writes a specific value of "55H" to this register, it will generate a reset
signal to reset whole chip.
• FC2 Register
Bit 7
Name —
R/W —
POR —
Bit 7~1 Unimplemented, read as "0"
Bit 0 CLWB: Flash memory Write Buffer Clear control
0: Do not initiate Write Buffer Clear process or Write Buffer Clear process is
1: Initiate Write Buffer Clear process
This bit is set by software and cleared by hardware when the
process
• FARL Register
Bit 7
Name A7
R/W R/W
POR 0
Bit 7~0 Flash Memory Address bit 7 ~ bit 0
• FARH Register – HT67F2350
Bit 7
Name —
R/W —
POR —
Bit 7~5 Unimplemented, read as "0"
Bit 4~0 Flash Memory Address bit 12 ~ bit 8
