HT67F2350/HT67F2360
HT67F2370/HT67F2390
Advanced A/D Flash MCU with LCD & EEPROM
Pad Name Function
PG2
PG2/COM2
COM2
PG3
PG3/COM3
COM3
PG4
PG4/COM0
COM0
PG5
PG5/COM1
COM1
PG6
PG6/COM2
COM2
PG7
PG7/COM3
COM3
PH0
PTP4I
PH0/PTP4I/PTP4/SEG20
PTP4
SEG20
PH1
PTP5I
PH1/PTP5I/PTP5/SEG19
PTP5
SEG19
PH2
PH2/PTCK4/AN12/
PTCK4
SEG42
AN12
SEG42
PH3
PH3/PTCK5/AN13/
PTCK5
SEG41
AN13
SEG41
PH4
PH4/PTCK6/AN14/
PTCK6
SEG40
AN14
SEG40
Rev. 1.60
OPT I/T O/T
PGPU
ST CMOS General purpose I/O. Register enabled pull-up.
PGS0
PGS0 — LCD LCD common output
PGPU
ST CMOS General purpose I/O. Register enabled pull-up.
PGS0
PGS0 — LCD LCD common output
PGPU
ST CMOS General purpose I/O. Register enabled pull-up.
PGS1
PGS1 — LCD LCD common output
PGPU
ST CMOS General purpose I/O. Register enabled pull-up.
PGS1
PGS1 — LCD LCD common output
PGPU
ST CMOS General purpose I/O. Register enabled pull-up.
PGS1
PGS1 — LCD LCD common output
PGPU
ST CMOS General purpose I/O. Register enabled pull-up.
PGS1
PGS1 — LCD LCD common output
PHPU
ST CMOS General purpose I/O. Register enabled pull-up.
PHS0
PHS0
ST — PTM4 capture input
IFS3
PHS0 — CMOS PTM4 output
PHS0 — LCD LCD segment output
PHPU
ST CMOS General purpose I/O. Register enabled pull-up.
PHS0
PHS0
ST — PTM5 capture input
IFS3
PHS0 — CMOS PTM5 output
PHS0 — LCD LCD segment output
PHPU
ST CMOS General purpose I/O. Register enabled pull-up.
PHS0
PHS0
ST — PTM4 clock input
IFS3
PHS0 AN — A/D Converter analog input
PHS0 — LCD LCD segment output
PHPU
ST CMOS General purpose I/O. Register enabled pull-up.
PHS0
PHS0
ST — PTM5 clock input
IFS3
PHS0 AN — A/D Converter analog input
PHS0 — LCD LCD segment output
PHPU
ST CMOS General purpose I/O. Register enabled pull-up.
PHS1
PHS1
ST — PTM6 clock input
IFS3
PHS1 AN — A/D Converter analog input
PHS1 — LCD LCD segment output
