• PES0 Register
Bit 7
Name PES07
R/W R/W
POR 0
PES07~PES06: PE3 pin function selection
Bit 7~6
00: PE3/PTP1I
01: PTP1
10: SCKA
11: SEG4
PES05~PES04: PE2 pin function selection
Bit 5~4
00, 01: PE2/PTCK1
10: SDIA
11: SEG5
PES03~PES02: PE1 pin function selection
Bit 3~2
00: PE1/STP0I
01: STP0
10: SDOA
11: SEG6
PES01~PES00: PE0 pin function selection
Bit 1~0
00, 01: PE0/STCK0
10: SCSA
11: SEG7
• PES1 Register
Bit 7
Name PES17
R/W R/W
POR 0
Bit 7~6 PES17~PES16: PE7 pin function selection
00, 01: PE7
10: V2
11: SEG53
Bit 5~4 PES15~PES14: PE6 pin function selection
00, 01: PE6
10: C1
11: SEG54
Bit 3~2 PES13~PES12: PE5 pin function selection
00, 01: PE5
10: C2
11: SEG55
Bit 1~0 PES11~PES10: PE4 pin function selection
00, 01, 10: PE4
11: Unimplemented
Rev. 1.60
6 5 4
PES06 PES05 PES04
R/W R/W R/W
0 0 0
6 5 4
PES16 PES15 PES14
R/W R/W R/W
0 0 0
123
3 2 1
PES03 PES02 PES01
R/W R/W R/W
0 0 0
3 2 1
PES13 PES12 PES11
R/W R/W R/W
0 0 0
May 16, 2019
0
PES00
R/W
0
0
PES10
R/W
0
