Bit 5~4 SLEDC35~SLEDC34: PH3~PH0 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 3~2 SLEDC33~SLEDC32: PG7~PG4 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 1~0 SLEDC31~SLEDC30: PG3~PG0 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
SLEDC4 Register – HT67F2350
Bit 7
Name —
R/W —
POR —
Bit 7~4 Unimplemented, read as "0"
Bit 3~2 SLEDC43~SLEDC42: PJ7~PJ6 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 1~0 SLEDC41~SLEDC40: PJ3~PJ0 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
SLEDC4 Register – HT67F2360/HT67F2370/HT67F2390
Bit 7
Name —
R/W —
POR —
Bit 7~4 Unimplemented, read as "0"
Bit 3~2 SLEDC43~SLEDC42: PJ7~PJ4 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 1~0 SLEDC41~SLEDC40: PJ3~PJ0 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Rev. 1.60
Advanced A/D Flash MCU with LCD & EEPROM
6 5 4
— — — SLEDC43 SLEDC42 SLEDC41 SLEDC40
— — —
— — —
6 5 4
— — — SLEDC43 SLEDC42 SLEDC41 SLEDC40
— — —
— — —
116
HT67F2350/HT67F2360
HT67F2370/HT67F2390
3 2 1
R/W R/W R/W
0 0 0
3 2 1
R/W R/W R/W
0 0 0
May 16, 2019
0
R/W
0
0
R/W
0
