SLEDC2 Register
Bit 7
Name SLEDC27 SLEDC26 SLEDC25 SLEDC24 SLEDC23 SLEDC22 SLEDC21 SLEDC20
R/W R/W
POR 0
Bit 7~6 SLEDC27~SLEDC26: PF7~PF4 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 5~4 SLEDC25~SLEDC24: PF3~PF0 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 3~2 SLEDC23~SLEDC22: PE4~PE7 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 1~0 SLEDC21~SLEDC20: PE3~PE0 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
SLEDC3 Register – HT67F2350
Bit 7
Name —
R/W —
POR —
Bit 7~4 Unimplemented, read as "0"
Bit 3~2 SLEDC33~SLEDC32: PG7~PG4 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
Bit 1~0 Unimplemented, read as "0"
SLEDC3 Register – HT67F2360/HT67F2370/HT67F2390
Bit 7
Name SLEDC37 SLEDC36 SLEDC35 SLEDC34 SLEDC33 SLEDC32 SLEDC31 SLEDC30
R/W R/W
POR 0
Bit 7~6 SLEDC37~SLEDC36: PH7~PH4 source current selection
00: source current=Level 0 (min.)
01: source current=Level 1
10: source current=Level 2
11: source current=Level 3 (max.)
