Holtek HT67F2350 Manual page 119

HT67F2350/HT67F2360
HT67F2370/HT67F2390
Advanced A/D Flash MCU with LCD & EEPROM
• PAS0 Register
Bit 7
Name PAS07
R/W R/W
POR 0
PAS07~PAS06: PA3 pin function selection
Bit 7~6
00, 01: PA3/INT1
10: SDO
11: SEG25
PAS05~PAS04: PA2 pin function selection
Bit 5~4
00, 01, 10: PA2
11: SEG29
PAS03~PAS02: PA1 pin function selection
Bit 3~2
00, 01: PA1/INT0
10: SCS
11: SEG26
PAS01~PAS00: PA0 pin function selection
Bit 1~0
00, 01, 10: PA0
11: SEG30
• PAS1 Register
Bit 7
Name PAS17
R/W R/W
POR 0
PAS17~PAS16: PA7 pin function selection
Bit 7~6
00, 01: PA7/INT1
10: TX0
11:SEG21
PAS15~PAS14: PA6 pin function selection
Bit 5~4
00, 01: PA6/INT0
10: RX0
11: SEG22
Bit 3~2 PAS13~PAS12: PA5 pin function selection
00, 01: PA5/INT3
10: SCK/SCL
11: SEG23
Bit 1~0 PAS11~PAS10: PA4 pin function selection
00, 01: PA4/INT2
10: SDI/SDA
11: SEG24
• PBS0 Register – HT67F2350/HT67F2360
Bit 7
Name PBS07
R/W R/W
POR 0
Bit 7~6 PBS07~PBS06: PB3 pin function selection
00, 01: PB3/PTP2I
10: PTP2
11: SEG27
Bit 5~4 PBS05~PBS04: PB2 pin function selection
00, 01: PB2/PTP3I/PTCK2
10: PTP3
11: SEG16
Rev. 1.60
6 5 4
PAS06 PAS05 PAS04
R/W R/W R/W
0 0 0
6 5 4
PAS16 PAS15 PAS14
R/W R/W R/W
0 0 0
6 5 4
PBS06 PBS05 PBS04
R/W R/W R/W
0 0 0
119
3 2 1
PAS03 PAS02 PAS01
R/W R/W R/W
0 0 0
3 2 1
PAS13 PAS12 PAS11
R/W R/W R/W
0 0 0
3 2 1
PBS03 PBS02 PBS01
R/W R/W R/W
0 0 0
May 16, 2019
0
PAS00
R/W
0
0
PAS10
R/W
0
0
PBS00
R/W
0
