6.5 Settings List

Description
Calibration
Channel 1
Ch1 Calibration
Ch1 Alarm Low Limit
Ch1 Alarm High Limit
Channel 2
Ch2 Calibration
Ch2 Alarm Low Limit
Ch2 Alarm High Limit
Altitude
Guaranteed Soak
PID Values
Channel 1
Proportional Band, Ch1 Heating
Reset, Ch1 Heating
Rate, Ch1 Heating
Cycle Time, Ch1 Heating
Rate Band, Ch1 Heating
Dead Band, Ch1
Proportional Band, Ch1 Cooling
Reset, Ch1 Cooling
Rate, Ch1 Cooling
Cycle Time, Ch1 Cooling
Rate Band, Ch1 Cooling
Channel 2
Proportional Band, Ch2 Heating
Reset, Ch2 Heating
Rate, Ch2 Heating
Cycle Time, Ch2 Heating
Rate Band, Ch2 Heating
Dead Band, Ch2
Proportional Band, Ch2 Cooling
Reset, Ch2 Cooling
Rate, Ch2 Cooling
Cycle Time, Ch2 Cooling
Rate Band, Ch2 Cooling
Synergy Controller Technical Manual, Revision H
Command Value
CAL1
A1L
A1H
CAL2
A2L
A2H
ALT
GS
PB1H
RS1H
RT1H
CT1H
RB1H
DB1
PB1C
RS1C
RT1C
CT1C
RB1C
PB2H
RS2H
RT2H
CT2H
RB2H
DB2
PB2C
RS2C
RT2C
CT2C
RB2C
