17.0 APPENDIX A COMMUNICATIONS

17.1 Frequently Used Commands

Setpoints and Process Variable
Commands
Query Channel Process Variable
Query Temperature (Chan.1)
Query Humidity (Chan.2)
Set Temperature Setpoint (Chan.1)
Query Temperature Setpoint (Chan.1)
Set Humidity Setpoint (Chan. Chan.2)
Query Humidity Setpoint (Channel 2)
On/Off Commands
Turn Chamber ON
Query Chamber ON state
Turn Chamber OFF
Event Output Commands
Set Event Output n ON
Set Event Output n OFF
Query State of Event Outputs
Program Commands
Query Program State
Load a Program
Start a Program
Start a Program at a specific line
Query Program state
Alarm Commands
Check Status of Alarms
Acknowledge Alarms
Synergy Controller Technical Manual, Revision H
Syntax
? Cn where n is the channel
? C1
? C2
= SP1 n
? SP1
= SP2 n
? SP2
Syntax
= ON
? ON
= OFF
Syntax
= EVENTS n, 1
= EVENTS n, 0
? EVENTS
Syntax
? RUN PROFILE_STATE
= FILEOPEN 1 "program-name"
= RUN
= RUNFROM n
? RUN
1= Run, 2 = Pause, 3 = Steady State
Syntax
? ALM
= ACKALM
Example
? C1
? C1
? C2
= SP1 25.0
? SP1
= SP2 50.0
? SP2
Example
= ON
? ON
= OFF
Example
= EVENTS 1, 1
= EVENTS 1, 0
? EVENTS
Example
= FILEOPEN 1
"Product1"
= RUN
= RUNFROM 2
? RUN
Example
? ALM
= ACKALM
Response
25.0
25.0
50.0
OK
25.0
OK
50.0
Response
OK
0 or 1
OK
Response
OK
OK
00FF0003
Response
OK
OK
OK
1
Response
1,0,00000800
OK
