Tidal Engineering Synergy Series Technical Manual page 246

Description Command Usages
VP_STDALT_SENID
Query
VP_HIALT_SENID Set
Virtual Pressure High Altitude
Sensor ID
VP_HIALT_SENID Query
VP_TRANS_PRESS Set
Virtual Pressure Transfer
Pressure
VP_TRANS_PRESS
Query
VP_TRANS_HYST Set
Virtual Pressure Transfer
Hysteresis
VP_TRANS_HYST Query
TC#_FLT_TYPE Set
Thermocouple # Filter Type
TC#_FLT_TYPE Query
TC#_FLT_MAXD Set
Thermocouple # IIR Filter Max
Delta
TC#_FLT_MAXD Query
TC#_FLT_WT Set
Thermocouple # IIR Filter
Weight
TC#_FLT_WT Query
TC#_FLT_SMPLS Set
Thermocouple # IIR Median
Filter Samples
TC#_FLT_SMPLS Query
Synergy Controller Technical Manual, Revision H
Command Syntax Range,
Units
110 - 999
See Technical Manual for complete
? VP_STDALT_SENID list
ARG1:
110 //for RTD1
120 //for RTD1
130 //for ANALOG 1
140 //for ANALOG 2
150 //for ANALOG 3
160 //for ANALOG 4
170 //for Nano TC 1
180 //for Nano TC 2
See Technical Manual for complete
list
= VP_HIALT_SENID ARG1
110 - 999
See Technical Manual for complete
? VP_HIALT_SENID list
= VP_TRANS_PRESS ARG1: 0 - 1200
ARG1
0 - 1200
? VP_TRANS_PRESS
= VP_TRANS_HYST ARG1: 0 - 1200
ARG1
0 - 1200
? VP_TRANS_HYST
# - Thermocouple 1 or 2
ARG1:
0 - No Filter
1 - IIR Filter
2 - Median Filter
3 - IIR+Median
4 - Median+IIR
= TC#_FLT_TYPE ARG1
Filter type 0 - 4
? TC#_FLT_TYPE
# - Thermocouple 1 or 2
ARG1 : 0 - 1 millivolts
= TC#_FLT_MAXD ARG1
0 - 1 millivolts
? TC#_FLT_MAXD
# - Thermocouple 1 or 2
ARG1: 0 - 100 Percent
= TC#_FLT_WT ARG1
0 - 100 Percent
? TC#_FLT_WT
# - Thermocouple 1 or 2
ARG1: 0 - 19
= TC#_FLT_SMPLS ARG1
0 - 19
? TC#_FLT_SMPLS
Command Response Example
Example
130
? VP_STDALT_SENID
OK
= VP_HIALT_SENID ARG1
140
? VP_HIALT_SENID
OK
= VP_TRANS_PRESS 100
100
? VP_TRANS_PRESS
OK
= VP_TRANS_HYST 100
100
? VP_TRANS_HYST
OK
= TC1_FLT_TYPE 0
0
? TC1_FLT_TYPE
OK
= TC1_FLT_MAXD 0.1
0.1
? TC1_FLT_MAXD
OK
= TC1_FLT_WT 33
33
? TC1_FLT_WT
OK
= TC1_FLT_SMPLS 5
5
? TC1_FLT_SMPLS
