20.4 Bar Code Scanner Installation
Connecting the Barcode Scanner
1. Connect the appropriate cable to the handle of the ImageTeam 4800 and screw on the retainer clip.
2. Connect the scanners USB cable to the Synergy Micro.
Configuring the Barcode scanner
Follow the steps below to configure the ImageTeam 4800 for use with the Synergy Controller and OCR-A
fonts. If a different configuration or barcode scanner is used, see Application note 4 for alternative settings
for other devices.
Synergy Controller Technical Manual, Revision H
Page 329
