Generic Temperature/Temperature, Dual Thermal Shock - Tidal Engineering Synergy Series Technical Manual

15.4.2 Generic Temperature/Temperature, Dual Thermal Shock

Generic Temp/Temp, Dual Thermal Shock
TE1151-12
TE1151-6
TE1151-6
TE1151-6
Synergy Controller Technical Manual, Revision H
1SM Outputs
SM Channel Digital Output
1
2
3
4
5
6
7
8
9
10
11
12
2SM Outputs
SM Channel Digital Output
1
2
3
4
5
6
3SM Event Outputs
SM Channel Digital Output
1
2
3
4
5
6
SSR Outputs
SM Channel Digital Output
1
2
3
4
5
6
Device
1 PID Heat
2 PID Cool
3 Compressor
4 Artificial Load
5 Fan
6 PID Heat
7 PID Cool
8 Compressor
9 Artificial Load
10 Fan
17 Event 1
18 Event 2
Device
11 Not Used
12 Not Used
13 Not Used
14 Not Used
15 Not Used
16 Not Used
Device
19 Event 1
20 Event 2
21 Event 3
22 Event 4
23 Event 5
24 Event 6
Device
25 Not Used
26 Not Used
27 Not Used
28 Not Used
29 Not Used
30 Not Used
Page 177
