Tidal Engineering Synergy Series Technical Manual page 182

Generic Temperature/Humidity Single Stage
Main Screen
Channels
Inputs Channel 1
Type Temperature
Sensor RTD1
High Volt Scale N/A
Low Volt Scale N/A
High Eng. Scale N/A
Low Eng. Scale N/A
Digital Inputs
Name
Ambient Lock Out
Drier Logic
Compressor Cut in Logic
Burn-in Logic
AGREE Chamber Logic
TempGard
Alarms
Name
Hi Alarm Ch 1
Low Alarm Ch 1
Hi Alarm Ch 2
Low Alarm Ch 2
Bad Sensor Ch 1
Bad Sensor Ch 1
Bad Sensor Ch 2
Bad Sensor Ch 2
TempGard
Synergy Controller Technical Manual, Revision H
Channel 2
Humidity
Analog 1
5VDC
0VDC
100%
0%
Input Function when Closed
Input 1 Disables Ambient Coil when Dehumidify Coil is on.
Input 2 Enables Drier when LEV1 (Use Drier) is active.
Input 3 Boost Heat, High Artificial Load, High Stage Compressor, Cascade
Condenser
Input 4 Enables Low Stage Compressor and Full Cool with LEV1.
Input 5 Locks out Low Stage Compressor and enables High Stage
Compressor and Full Cool with LEV1
Input 9 None, TempGard Alarm displays in Alarm Folder and Log File.
Sensor Sensor
Code
RTD1 110
RTD1 110
Analog1 130
Analog1 130
RTD1 110
RTD1 110
Analog1 130
Analog1 130
Digital Input 9 409
Digital Output Screen
Channel 3
N/A
N/A
N/A
N/A
N/A
N/A
(See Section 6.7 Device Primitives
Default
Threshold
> 500 C
< -200C
104%
-10%
< 10 Ohm
> 330 Ohm
< -.1 Vdc
> 5.25 Vdc
Open
Channel 4
N/A
N/A
N/A
N/A
N/A
N/A
etc.)
Report Log K1
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes No
Page 182
K2
No
No
No
No
No
No
No
No
No
