Tidal Engineering Synergy Series Technical Manual page 269

Description Command Usages
Logic Primitive Function 4
LOGIC#_FUNC4 Set
LOGIC#_FUNC4 Query
Logic Primitive Function Type
LOGIC#_TYPE Set
LOGIC#_TYPE Query
Logic Primitive Activation
LOGIC#_ONT Set
(ON) Delay
LOGIC#_ONT Query
Logic Primitive Deactivation
LOGIC#_OFFT Set
(OFF) Delay
LOGIC#_OFFT Query
Logic Primitive Enable when
LOGIC#_ENA_OFF Set
Controller Off
LOGIC#_ENA_OFF
Query
On/Off Retransmit Activation
ONOFF#_ONT Set
(ON) Delay
ONOFF#_ONT Query
On/Off Retransmit
ONOFF#_OFFT Set
Deactivation (OFF) Delay
ONOFF#_OFFT Query
On/Off Retransmit Enable
when Controller Off
ONOFF#_ENA_OFF Set
Panel Lock Enable
PL_ENABLED Set
PL_ENABLED Query
Panel Lock Enable On/Off
PL_ENABLE_ONOFF Set
Button
PL_ENABLE_ONOFF
Query
Synergy Controller Technical Manual, Revision H
Command Syntax Range,
Units
# - Logic Primitive 1 - 16
ARG1:
110 - 1299
See Technical Manual for complete
= LOGIC#_FUNC4 ARG1 list
? LOGIC#_FUNC4
# - Logic Primitive 1 - 16
ARG1:
0 - AND
1 - OR
2 - NAND
= LOGIC#_TYPE ARG1 3 - NOR
? LOGIC#_TYPE
# - Logic Primitive 1 - 16
= LOGIC#_ONT ARG1 ARG1: 0 - 3600 Seconds
? LOGIC#_ONT
# - Logic Primitive 1 - 16
= LOGIC#_OFFT ARG1 ARG1: 0 - 3600 Seconds
? LOGIC#_OFFT
= LOGIC#_ENA_OFF # - Logic Primitive 1 - 16
ARG1 ARG1: 0 - Disabled, 1 - Enabled
? LOGIC#_ENA_OFF
# - On/Off Retransmit 1 - 8
= ONOFF#_ONT ARG1 ARG1: 0 - 3600 Seconds
? ONOFF#_ONT
# - On/Off Retransmit 1 - 8
= ONOFF#_OFFT ARG1 ARG1: 0 - 3600 Seconds
? ONOFF#_OFFT
= ONOFF#_ENA_OFF # - On/Off Retransmit 1 - 8
ARG1 ARG1: 0 - Disabled, 1 - Enabled
Panel Lock Commands
ARG1:
= PL_ENABLED ARG1 0 - Unlocked, 1 - Locked
? PL_ENABLED 0 - Unlocked, 1 - Locked
= PL_ENABLE_ONOFF ARG1:
ARG1 0 - Disabled, 1 - Enabled
? PL_ENABLE_ONOFF 0 - Disabled, 1 - Enabled
Command Response Example
Example
= LOGIC1_FUNC4 1004 OK
? LOGIC1_FUNC4 1004
= LOGIC1_TYPE 2 OK
? LOGIC1_TYPE 2
= LOGIC1_ONT 30 OK
? LOGIC1_ONT 30
= LOGIC1_OFFT 30 OK
? LOGIC1_OFFT 30
= LOGIC1_ENA_OFF 1 OK
? LOGIC1_OFFT 1
= ONOFF1_ONT 60 OK
? ONOFF1_ONT 60
= ONOFF1_OFFT 60 OK
? ONOFF1_OFFT 60
= ONOFF1_ENA_OFF 1 OK
= PL_ENABLED 1 OK
? PL_ENABLED 1
= PL_ENABLE_ONOFF 1 OK
? PL_ENABLE_ONOFF 1
