Tidal Engineering Synergy Series Technical Manual page 243

Description Command Usages
DRYB_SENID Set
Dry Bulb Sensor Select ID
DRYB_SENID Query
WBDB_ALT Set
Wet Bulb/Dry Bulb Altitude
Compensation in Torr
WBDB_ALT Query
TC_FILTER Set
Thermocouple Filtering
Enable
TC_FILTER Query
TC#_GAIN Set
Thermocouple # Gain
TC#_GAIN Query
TC#_OFF Set
Thermocouple # Offset
TC#_OFF Query
TC#_TYPE Set
Thermocouple # Type
TC#_TYPE Query
Retransmit # High
Engineering Units
OUT#_HIGHEU Set
OUT#_HIGHEU Query
Retransmit # Low Engineering
Units
OUT#_LOWEU Set
OUT#_LOWEU Query
OUT#_HIGHV Set
Retransmit # High Volts
OUT#_HIGHV Query
OUT#_LOWV Set
Retransmit # Low Volts
Synergy Controller Technical Manual, Revision H
Command Syntax Range,
Units
= DRYB_SENID ARG1 ARG1 - ID of the Sensor. 100 -
999.
? DRYB_SENID ID of the Sensor. 100 - 999.
= WBDB_ALT ARG1 ARG1:
0 - 5000 Torr
? WBDB_ALT 0 - 5000 Torr
= TC_FILTER ARG1 ARG1:
0 = Disabled
1 = Enabled
? TC_FILTER 0 = Disabled
1 = Enabled
= TC#_GAIN ARG1 ARG1 - 25-200%
? TC#_GAIN 25 - 200%
= TC#_OFF ARG1 ARG1: -1000.00 to 1000.00 uV
? TC#_OFF -1000.00 to 1000.00 uV
= TC#_TYPE ARG1 ARG1:
0 - B Type
1 - E Type
2 - J Type
3 - K Type
4 - R Type
5 - S Type
6 - T Type
? TC#_TYPE
= OUT#_HIGHEU ARG1 # is 1 for Retransmit 1, 2 for
Retransmit 2
ARG1 -500 - 5000 units
? OUT#_HIGHEU -500 - 5000 units
= OUT#_LOWEU ARG1 # is 1 for Retransmit 1, 2 for
Retransmit 2
ARG1 -500 - 5000 units
? OUT#_LOWEU -500 - 5000 units
= OUT#_HIGHV ARG1 # is 1 for Retransmit 1, 2 for
Retransmit 2
ARG1 0.0 - 5.250 Volts
? OUT#_HIGHV 0.0 - 5.250 Volts
= OUT#_LOWV ARG1 # is 1 for Retransmit 1, 2 for
Retransmit 2ARG1 0.0 - 5.250
Volts
Command Response Example
Example
= DRYB_SENID 110 OK
? DRYB_SENID 110
= WBDR_ALT 760 OK
? WBDB_ALT 760
= TC_FILTER 1 OK
? TC_FILTER 1
= TC1_GAIN 105 OK
? TC1_GAIN 105
= TC1_OFF 0.001 OK
? TC1_OFF 0.01
= TC1_TYPE 6 OK
? TC1_TYPE 6
= OUT1_HIGHEU 500 OK
? OUT1_HIGHEU 500.0
= OUT1_LOWEU -100 OK
? OUT1_LOWEU -100.0
= OUT1_HIGHV 5 OK
? OUT1_HIGHV 5.000
= OUT1_LOWV 0 OK
