Tidal Engineering Synergy Series Technical Manual page 235

Description Command Usages
REG_KEY_CAS Query
REG_KEY_PRES Set
Register Pressure Key
REG_KEY_PRES Query
CUSTCHAMBERNAME
Set
Customer Chamber Name
CUSTCHAMBERNAME
Query
AIR* Query
CH * Air Actual (changes
based on Cascade Mode)
CC* Query
AIRSP* Query
CH * Air Setpoint (changes
based on Cascade Mode) CSP* Query
OUT_420_#V2 Set
Retransmit # Source
OUT_420_#V2 Query
Storage Card Info SCINFO Query
RAM Info MEMINFO Query
Software Revision *IDN Query
OVERSION Query
Olympic Board Version
Synergy Controller Technical Manual, Revision H
Command Syntax Range,
Units
? REG_KEY_CAS Cascade License Key
= REG_KEY_PRES ARG1 ARG1: "Pressure License Key"
? REG_KEY_PRES Pressure License Key
= CUSTCHAMBERNAME ARG1: "Custom Chamber Name"
ARG1
? CUSTCHAMBERNAME Custom Chamber Name
? AIR* If CH* Cascade = Off, CH* Actual
If CH* Cascade = On, CH*
Cascade Actual
? CC* If CH* Cascade = Off, CH* Actual
If CH* Cascade = On, CH* Product
Actual
? AIRSP* If CH* Cascade = Off, CH* Setpoint
If CH* Cascade = On, CH*
Cascade Setpoint
? CSP* If CH* Cascade = Off, CH* Setpoint
If CH* Cascade = On, CH* Product
Setpoint
= OUT_420_#V2 ARG1 # - 1 or 2
ARG1:
110 - 1299
See Technical Manual for complete
list
? OUT_420_#V2
System Commands
? SCINFO returns storage card free
? MEMINFO Returns total system RAM and
available RAM
*IDN ? Returns Revision Info: Make,
Model, Serial number, Version
? OVERSION Olympic board Version and Serial
Number
Command Response Example
Example
? REG_KEY_CAS "License Key"
= REG_KEY_PRES "License OK
Key"
? REG_KEY_PRES "License Key"
= CUSTCHAMBERNAME "My OK
Chamber"
? CUSTCHAMBERNAME My Chamber
? AIR1 25.5
? CC1 25.5
? AIRSP1 25.5
? CSP1 25.5
= OUT_420_1V2 710 OK
? OUT_420_1V2 710
? SCINFO Total: 8128512, Free:
1826816
? MEMINFO Unknown, Total Physical:
20242432, Available
Physical: 14848000, RAM
*IDN? Tidal Engineering,
Synergy Controller,Serial-
13/0137,Version 2.6.8
? OVERSION Olympic V0.0.35, 13/0137
