13.2.3 Sensor Displays

Additional sensor values can be displayed on the Main screen for UUT test and other variables.
Up to 8 Sensor Displays can be shown on the Main screen as shown below:
Up to 8 Sensors
Synergy Controller Technical Manual, Revision H
Sensor 3
Sensor 4
Sensor 5
Medium Display Channel Text
Sensor 6
Sensor 7
Sensor 8
Sensor 9
Sensor 10
Page 150
