15.4.4 Generic Temperature/Humidity Single Stage

Generic Temperature/Humidity Single Stage
TE1151-12
TE1151-6
TE1151-6
TE1151-5
Synergy Controller Technical Manual, Revision H
1SM Outputs
SM Channel Digital Output
1
2
3
4
5
6
7
8
9
10
11
12
2SM Outputs
SM Channel Digital Output
1
2
3
4
5
6
3SM Event Outputs
SM Channel Digital Output
1
2
3
4
5
6
SSR Outputs
SSR Channel Digital Output
1
2
3
4
5
6
Device
1 Fan
2 High Artificial Load
3 PID Heat
4 Boost Heat
5 Wickpan
6 High Compressor
7 PID Cool
8 Full Cool
9 Ambient
10 PID Humidity
17 Dehumidify Coil
18 Drier
Device
11 Not Used
12 Not Used
13 Not Used
14 Not Used
15 Not Used
16 Not Used
Device
19 Event 1
20 Event 2
21 Event 3
22 Event 4
23 Event 5
24 Event 6
Device
25 Not Used
26 Not Used
27 Not Used
28 Not Used
29 Not Used
30 Not Used
Page 181
