Tidal Engineering Synergy Series Technical Manual page 267

Description Command Usages
PWM Cycle Time PWM#CYCLE Set
PWM#CYCLE Query
ON/Off Retransmit Source
ONOFF#_SRC Set
ONOFF#_SRC Query
On/Off Retransmit High Eng.
ONOFF#_ENGMAX Set
Threshold
ONOFF#_ENGMAX
Query
On/Off Retransmit Low Eng.
ONOFF#_ENGMIN Set
Threshold
ONOFF#_ENGMIN Query
On/Off Retransmit Hysteresis ONOFF#_HYST Set
ONOFF#_HYST Query
ONOFF#_ACTST Set
On/Off Retransmit Active
State
ONOFF#_ACTST Query
Synergy Controller Technical Manual, Revision H
Command Syntax Range,
Units
# - A Number from 1 to 8
= PWM#CYCLE ARG1 ARG1: 0 - 60 Seconds
? PWM#CYCLE 0 - 60 Seconds
# - A Number from 1 to 8
ARG1:
0 - Off
1 - CH1 Actual
2 - CH2 Actual
3 - CH3 Actual
4 - CH1 Setpoint
5 - CH2 Setpoint
6 - CH3 Setpoint
7 - CH1 Heat PID
8 - CH1 Cool PID
9 - CH2 Heat PID
10 - CH2 Cool PID
11 - CH3 Heat PID
12 - CH3 Cool PID
13 - CH1 Cascade Air
14 - CH2 Cascade Air
15 - CH3 Cascade Air
16 - CH1 Full PID
17 - CH2 Full PID
= ONOFF#_SRC ARG1 18 - CH3 Full PID
? ONOFF#_SRC 0 - 18
# - A Number from 1 to 8
= ONOFF#_ENGMAX
ARG1: -200 - 5000
ARG1
? ONOFF#_ENGMAX -200 to 5000
# - A Number from 1 to 8
= ONOFF#_ENGMIN
ARG1: -200 - 5000
ARG1
? ONOFF#_ENGMIN -200 to 5000
# - A Number from 1 to 8
ARG1: -200 - 5000
= ONOFF#_HYST ARG1
? ONOFF#_HYST -200 to 5000
= ONOFF#_ACTST ARG1 ARG1: 0 - Off, 1 - On
0 - Off,
? ONOFF#_ACTST
Command
Example
= PWM1CYCLE 7
? PWM1CYCLE
= ONOFF1_SRC 4
? ONOFF1_SRC
= ONOFF1_ENGMAX 50
? ONOFF1_ENGMAX
= ONOFF1_ENGMIN 20
? ONOFF1_ENGMIN
= ONOFF1_HYST 5
? ONOFF1_HYST
= ONOFF1_ACTST 1
1 - On
? ONOFF1_ACTST
Response Example
OK
7
OK
4
OK
50
OK
20
OK
5
OK
1
