Tidal Engineering Synergy Series Technical Manual page 255

Description Command Usages
FILEOPEN Set
Open a downloaded file
VTVINFO Set
Set information regarding the
profile being downloaded.
Use immediately after a
FILENEW command
STP
Program Step
FILE # See Program Step
STEP # See Program Step
See Program Step
STEPTYPE
See Steptype
SETPOINT
See Steptype
JUMPLOOP
Synergy Controller Technical Manual, Revision H
Command Syntax Range,
Units
= FILEOPEN 1 "file name" ARG1 = Filename to save to
= VTVINFO ARG1 ARG2 ARG1 - Major Version # of file. Is 1
ARG3 ARG4 ARG2 - Minor Version # of file. Is 0
This is only for use in ARG3 - Revision Version # of file.
saved files. Is 0
ARG4:
0 - File is saved in C
1 - File is saved in F
= STP File # Step # See File, Step, Step Type, etc.
STEPTYPE ARG4 ARGn parameters below
N/A Constant Parameter 1
N/A Range 1-255
N/A 0 = Setpoint
1 = Jumploop
2 = Waitfor
3 = Autostart
4 = Stop
5 = Link
ARG4 ARG5 ... ARG31 ARG4 = CH1 SP X 10ARG5 = CH2
SP X 10ARG6 = Ramp Hours X
10ARG7 = Ramp Minutes X
10ARG8 = Ramp Seconds X
10ARG9 - 14 = Event 1 - 6 (10=on,
0 = off)ARG15 - 16 = 0 (Not Used)
ARG17 = CH3 SP X 10 (-10000 =
off)
ARG18 = CH4 SP X 10 (-10000 =
off)
ARG19 - 28 = 0 (Not Used)
ARG29 = LEV1 (10=on, 0 = off)
ARG30 = LEV2 (10=on, 0 = off)
ARG31 = OT11
NOTE: ARG 4 thru ARG 31 are
X10
ARG4 ARG5 ARG4 = Jump Step X 10
ARG5 = Jump Count X 10 (-10 =
infinite)
NOTE: ARG 4 thru ARG 5 are
X10
Command Response Example
Example
= FILEOPEN MyProfile
= VTVINFO 1 0 0 0
= STP 1 1 0
N/A
N/A
10 (CH1= 1.0 Deg.)600 (CH2= OK
60.0 Deg.)10 (1.0 Hours)225
(22.5 Minutes)0 (0 Seconds)10
0 0 0 10 0 (on,off,off,off,on,off)0
0 (Not Used)
-10000 (CH3= Off)
-10000 (CH4= Off)
0 0 0 0 0 0 0 0 0 0 (Not Used)
0 (LEV1= Off)
10 (LEV2= On)
10 (OT11= Time Prop.)
200 (Jump to Line 20) OK
150 (Jump 15 times)
