5.2 User Interface

SETUP MAINT
The Following Folders and Screen Editors Will Appear When Pressed
Calibration Machine
Inputs
PID Alarms
Settings
Special Channel
Functions PIDs
L - Values About
LCD File Utilities
Settings
Chamber Date &
Setup Time
Logging Macro
Utilities
Panel Lock
Languages
Note: Green cells highlight new folders in this Synergy Controller software release.
Synergy Controller Technical Manual, Revision H
SCREEN NAVIGATION KEYS
COMM PROGRAM
RS - 232 Screen
Editor
RS - 485
Create, edit,
or load
IEEE - 488
profile
Ethernet
Web Server
TCP / IP
Server
RUN EVENTS
Screen Event
Editor Outputs
UUT
Run Profile
Temps.
Digital
Outputs
Digital
Inputs
Hi Res
Inputs
Lo Res
Inputs
Help Key: context
sensitive help.
BMP Key: take
screen shots.
Turn Chamber
ON or OFF
Select Keys:
Help with
entering data
and selecting
from lists &
groups
GRAPH MAIN
Graph Screen
Screen Editor
Large
Graphic
Manual
Display
Mode
Operating
Screen
w/ Small
Graphic
Display
Page 23
