Generic Temperature/Vibration (HALT/HASS)
Main Screen
Channels
Inputs Channel 1
Type Temperature
Sensor RTD1
High Volt Scale N/A
Low Volt Scale N/A
High Eng. Scale N/A
Low Eng. Scale N/A
Digital Inputs
Name
TempGard
Alarms
Name
Hi Alarm Ch 1
Low Alarm Ch 1
Hi Alarm Ch 2
Low Alarm Ch 2
Bad Sensor Ch 1
Bad Sensor Ch 1
Bad Sensor Ch 2
Bad Sensor Ch 2
TempGard
This Generic Temperature/Vibration configuration supports QualMark HALT/HASS Chamber retrofits.
Synergy Controller Technical Manual, Revision H
Channel 2
Vibration
Analog 1
5VDC
0VDC
100 Grms
0 Grms
Input Function when Closed
Input 9 None, TempGard Alarm displays in Alarm Folder and Log File.
Sensor Sensor
Code
RTD1 110
RTD1 110
Analog1 130
Analog1 130
RTD1 110
RTD1 110
Analog1 130
Analog1 130
Digital Input 9 409
Digital Output Screen
Channel 3
N/A
N/A
N/A
N/A
N/A
N/A
Default Report
Threshold
> 500 C Yes
< -200C Yes
104 Grms Yes
0 Grms Yes
< 10 Ohm Yes
> 330 Ohm Yes
< -.1 Vdc Yes
> 5.25 Vdc Yes
Open Yes
Channel 4
N/A
N/A
N/A
N/A
N/A
N/A
Log K1 K2
Yes Yes No
Yes Yes No
Yes Yes No
Yes Yes No
Yes Yes No
Yes Yes No
Yes Yes No
Yes Yes No
Yes No No
