15.4.1 Generic Temperature Only

TE1151-12
TE1151-6
TE1151-6
TE1151-6
Synergy Controller Technical Manual, Revision H
Generic Temperature Only
SM Channel
SM Channel
SM Channel
SM Channel
1SM Outputs
Digital Output
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 10
11 17
12 18
2SM Outputs
Digital Output
1 11
2 12
3 13
4 14
5 15
6 16
3SM Event Outputs
Digital Output
1 19
2 20
3 21
4 22
5 23
6 24
SSR Outputs
Digital Output
6 30
5 29
4 28
3 27
2 26
1 25
Device
Fan
Hi Artificial Load
PID Heat
Boost Heat
Low Compressor
High Compressor
PID Cool
Full Cool
Low Artificial Load
Cascade
Not Used
Not Used
Device
Not Used
Not Used
Not Used
Not Used
Not Used
Not Used
Device
Event 1
Event 2
Event 3
Event 4
Event 5
Event 6
Device
Not Used
Not Used
Not Used
Not Used
Not Used
Not Used
