Tidal Engineering Synergy Series Technical Manual page 238

Description Command Usages
RSM_PROFILE Set
RSM_PROFILE
Controls the behavior of the
RSM_PROFILE Query
controller running a profile after
a power failure.
DIF Set
Force Digital Input State
DIF Query
DIT Set
Toggle Digital Input State
DIT Query
Chamber Time TIME Query
EVENT#_NAME Set
Event # Name
EVENT#_NAME Query
420_#_ENAOFF Set
Retransmit when Chamber Off
420_#_ENAOFF Query
PROFILE_ALM_BEHAVI
OR Set
Profile Alarm Behavior
PROFILE_ALM_BEHAVI
OR Query
EVENT_SHOW_HUMID
Event Screen Display Set
Humidity EVENT_SHOW_HUMID
Query
ANLGCH*_ENA Set
Analog Programming CH*
Enabled ANLGCH*_ENA Query
Synergy Controller Technical Manual, Revision H
Command Syntax Range,
Units
= RSM_PROFILE ARG1 ARG1
0 = Chamber Off
1 = Resume Profile
2 = Watchdog Setpoint(s)
? RSM_PROFILE Returns:
0 = Chamber Off
1 = Resume Profile
2 = Watchdog Setpoint(s)
= DIF ARG1 ARG2 ARG1: Inputs 1 - 16
ARG2: "Open', "Close", or no
ARG2 to Clear
? DIF
= DIT ARG1 ARG2 ARG1: Inputs 1 - 16
ARG2: "Open', "Close", or no
ARG2 to Clear
? DIT
? TIME
= EVENT#_NAME "ARG1" # - Event Number 1 - 9
ARG1:
String with Event Name
? EVENT#_NAME
= 420_#_ENAOFF ARG1 ARG1:
0 - Disabled, 1 - Enabled
? 420_#_ENAOFF 0 - Disabled, 1 - Enabled
= ARG1: 0 -Stop Profile, 1 - Pause
PROFILE_ALM_BEHAVIO Profile
R ARG1
?
PROFILE_ALM_BEHAVIO
R
= EVENT_SHOW_HUMID ARG1: 0 - Disabled, 1 - Enabled
ARG1
? EVENT_SHOW_HUMID
= ANLGCH*_ENA ARG1 ARG1: 0 - No, 1 - Yes
? ANLGCH*_ENA 0 - No,
Command
Example
= RSM_PROFILE 2
? RSM_PROFILE
? TIME
= EVENT1_NAME "Light"
? EVENT1_NAME
= 420_1_ENAOFF 1
? 420_1_ENAOFF
= PROFILE_ALM_BEHAVIOR 1
? PROFILE_ALM_BEHAVIOR
= EVENT_SHOW_HUMID 1
? EVENT_SHOW_HUMID
= ANLGCH1_ENA 1
1 - Yes ? ANLGCH1_ENA
Response Example
OK
2
0.729236111
OK
Light
OK
1
OK
1
OK
1
OK
1
