Tidal Engineering Synergy Series Technical Manual page 239

Description Command Usages
ANLGCH*_INP Set
Analog Programming CH*
Sensor
ANLGCH*_INP Query
SCANNER_LOCKOUT
Set
Barcode Scanner Lockout
SCANNER_LOCKOUT
Query
ANLGCH*_ENA Set
Analog Programming CH*
Enabled ANLGCH*_ENA Query
ANLGCH*_INP Set
Analog Programming CH*
Sensor
ANLGCH*_INP Query
SCANNER_LOCKOUT
Set
Barcode Scanner Lockout
SCANNER_LOCKOUT
Query
UUT Set
Enable/Disable UUT
Monitoring
Synergy Controller Technical Manual, Revision H
Command Syntax Range,
Units
= ANLGCH*_INP ARG1 ARG1:
110 //for RTD1
120 //for RTD1
130 //for ANALOG 1
140 //for ANALOG 2
150 //for ANALOG 3
160 //for ANALOG 4
170 //for Nano TC 1
180 //for Nano TC 2
See Technical Manual for complete
list
? ANLGCH*_INP 110 - 999
See Technical Manual for complete
list
= SCANNER_LOCKOUT ARG1:
ARG1 0 - Disabled, 1 - Enabled
? SCANNER_LOCKOUT 0 - Disabled, 1 - Enabled
= ANLGCH*_ENA ARG1 ARG1: 0 - No, 1 - Yes
? ANLGCH*_ENA 0 - No,
= ANLGCH*_INP ARG1 ARG1:
110 //for RTD1
120 //for RTD1
130 //for ANALOG 1
140 //for ANALOG 2
150 //for ANALOG 3
160 //for ANALOG 4
170 //for Nano TC 1
180 //for Nano TC 2
See Technical Manual for complete
list
? ANLGCH*_INP 110 - 999
See Technical Manual for complete
list
= SCANNER_LOCKOUT ARG1:
ARG1 0 - Disabled, 1 - Enabled
? SCANNER_LOCKOUT 0 - Disabled, 1 - Enabled
Data Acquisition Commands
= UUT ARG1 ARG2 ARG1 = UUT # (1 - 8)
ARG2 = 0/1 (Enable / Disable)
Command
Example
= ANLGCH1_INP 140
? ANLGCH1_INP
= SCANNER_LOCKOUT 1
? SCANNER_LOCKOUT
= ANLGCH1_ENA 1
1 - Yes ? ANLGCH1_ENA
= ANLGCH1_INP 140
? ANLGCH1_INP
= SCANNER_LOCKOUT 1
? SCANNER_LOCKOUT
= UUT 1 1
Response Example
OK
140
OK
1
OK
1
OK
140
OK
1
OK
